PVD Decorative Coating Equipment, Decorative Coatings on Bathroom Fittings, PVD Vacuum Plating Equipment

Name: PVD Decorative Coating Equipment Decorative Coatings on Bathroom Fittings PVD Vacuum Plating Equipment
Brand: ROYAL
Price: 1 USD

Wholesale PVD Decorative Coating Equipment, Decorative Coatings on Bathroom Fittings, PVD Vacuum Plating Equipment from china suppliers

Brand Name : ROYAL

Model Number : RTAS1600

Certification : CE

Place of Origin : Made in China

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 10 sets per month

Delivery Time : 8 to 12 weeks

Packaging Details : Export standard, to be packed in new cases/cartons, suitable for long-distance ocean/air and inland transportation.

Chamber : Vertical Orientation, 1-DOOR

Material : Stainless Steel 304/316

Deposition Sources : MF/DC sputtering + Arc evaporation

Deposition Films : Hard coatings, DLC, Optical film coating

Applications : Optical Lens, tools, Glass slides, Ceramic sheets, SS circular board ,Medical Instruments

Film Features : High Reflective, Excellent Corrosion And Wear Resistance

Coating Colors : Black Color And Rose Gold, Blue Colors Coating

Factory Location : Shanghai city, China

Worldwide Service : Poland - Europe; Iran- West Asia & Middle East, Turkey, India, Mexico- South America

Training Service : Machine operation, maintenance, coating process Recipes, program

Warranty : Limited warranty 1 year for free, whole life for machine

OEM & ODM : available, we support tailor made design and fabrication

Contact Now

PVD Decorative Coating Equipment, Decorative Coatings on Bathroom Fittings, PVD Vacuum Plating Equipment

RTAC1618-SP PVD coating equipment mainly for decoration coatings on the metal, ABS parts. The ranged colors are silver, black, gold. When introducing different reactive gas and target materials the colors are changing slowly, during the deposition changing period, to get the idea desired colors.

This is operated by changing different coating parameters and process.

Coating processes to deposit every each color is stored in PLC software recipes, totally 10 recipes are available. So that the AUTO COATING model is possible after the recipes is logged in. The full automatically operation is very helpful for primer PVD operators.

Royal Technology provides you not only the coating machine but the total coating solutions, turnkey-project service is available.

The advantages:

PVD sputtering + Ion Plating give a combination of advantages like no other can:
1. Economically efficient, generating the thinnest, most uniform coating films;
2. A dry coating process at low temperature in a vacuum chamber;
3. Offers great versatility and can be used for the deposition of conductive or non-conductive materials on any type of substrates, like: metals, ceramics, plastic materials.
4. Multi-layered coating are simple to produce.

5. Fast deposition rates and high quality surface finishes.

RTAC1618-SP machine coating technology:

The planar magnetron sputtering cathodics (cylindrical sputtering cathodic) introducing, makes the coating colors is more reflective, coating surface is much more smoother, no spot and niddle holes.

High quality coating products satisified the demand of high level's pursuing.

3. Arc + Sputtering Coating Equipment Models

Model	Size(mm)	Number of Planetary Rods	Cathodic Arc Sources	Sputtering Cathodes	Ion Source	Bias Power Supply (kVA)
RTAC950-SP	950xH1350 2-doors	3	8	4 Planar	Linear Anode	1*36
RTAC1213-SP	1250xH1350 2-doors	48	8	4 Planar	Linear Anode	1*30, AE
RTAC1250-SP	1250xH1250	6,8,12,16	8	4~8 Cylinder	depends on coating process and product	1*36
RTAC1008-SP	1000xH800	3	6	2 Cylinder		1*24
RTAC1616-SP	1600xH1600	6*6	9	2 Cylinder or Planar		1*48
RTAC1618-SP	1600x1800	6,8,10	18	4 Cylinder		1*48

PVD Decorative Coating Equipment, Decorative Coatings on Bathroom Fittings, PVD Vacuum Plating Equipment

Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
